We The People Revolver

We The People Revolver
  • Color: Matt Skipper Green
  • Color: Matt Skipper Green
$1,249.00
Color: Matt Skipper Green
Size: 21-inch
Please select options Unavailable

Details

Taking our "do-it-all" aftermarket Revolver frame and draping it in some high-end components, we've managed to create an incredibly sophisticated and balanced bike for the kind of rider that appreciates the finer things in life. The longer 21" top tube and perfect all-round geometry make the Revolver perfectly comfortable on any terrain from the deep end of a bowl to the main line of your local trails or even the back streets of a big city. The harder 28-9 gearing gives this rig plenty of juice when the time for pedaling fast comes into play, and the full assortment of ECLAT Dura chromoly pegs and hub guards allow you to gun it down any rail in sight. Wrap it up with a lifetime-guaranteed ECLAT Storm fork and a Skipper Green paint finish, and the need to build a custom bike no longer exists.

Geometry

A: Top Tube Length:  21"

B: Chain Stay Length: 13.5" (13.2"-13.75")

C: Head Tube Angle: 74.75°

D: Seat Tube Angle: 71°

E: Bottom Bracket Height: 11.5"

F: Stand Over Height: 9.1"

Bar Geometry

G: Bar Rise: 9.25"

H: Bar Width: 29.7"

I: Bar Back Sweep: 11°

J: Bar Up Sweep: 2.5°

Specs

Frame WETHEPEOPLE "REVOLVER" frame, 4130 full sanko, invest cast wishbone & 7.5mm dropouts
Fork ÉCLAT "STORM" fork, post liquid heat-treated & butted sanko tubing, 30mm offset
Rims WETHEPEOPLE "LOGIC" 36mm double wall welded rim, 36h
Hubs Front Hub: ÉCLAT "PULSE " hub, sb, 3/8"'s axle, 36h
Rear Hub: ÉCLAT "PULSE" cassette, sb hub, 9T, 14mm axle, 36h, SDS driver
Tires WETHEPEOPLE "OVERBITE" tire, 2.35" front & rear
Bottom Bracket WETHEPEOPLE "COMPACT" 22mm, press fit, sealed bearing
Crankset WETHEPEOPLE "LOGIC" 22mm tubular 3pc crank crmo, 175mm, 48 spline
Cassette/Freewheel 9T, 1pc cassette driver, full bushing, SDS (RSD/LSD switchable)
Chain ÉCLAT "DIESEL" chain
Brakes ÉCLAT "TALON" alloy u-brake-rear
Brake Levers SALT "MOTO" alloy brake lever
Handlebars WETHEPEOPLE "REVOLVER" bar, post liquid heat-treated 4130 crmo
Tape/Grips ÉCLAT "FILTER" grips, flangeless, with ÉCLAT "TECH-BOLT" barends
Stem ÉCLAT "METRA" topload stem, cnc alloy, 51mm reach, 30mm rise
Headset WETHEPEOPLE "" int. headset, sealed bearing
Seatpost WETHEPEOPLE "TEAM" pivotal seat post, 606-T6 alloy, 200mm long
Saddle ÉCLAT "BIOS" slim padded pivotal seat
Pedals WETHEPEOPLE "LOGIC" nylon/fiberglass pedals
Accessories & Extras Hubguards: ÉCLAT "PULSE" 4140 chromoly x2

* Subject to change without notice.

Part Numbers

Option UPC MPN Store SKU
Matt Skipper Green / 21-inch 04055822507202 1001170121 210000075237
